Model
HT-300J IP

Light source
Light Sources: 260W Laser
laser life expectancy: 20000hrs

Optical system
Advanced laser optical design to ensure straight beam effect and high brightness
Diameter of frontal lens: 230 mm
Beam Angle: 0°-0.8°

Control and Program
o 4-buttons touch panel
o Display: LCD display
o Protocols: DMX512, RDM
o DMX Channel: 16
o Firmware Upgrade: Upgrade via DMX link
o Pan/Tilt Resolution: 16 bit

PAN & TILT
o Pan movement: 540°
o Tilt movement: 270°
o Automatic Pan/Tilt position correction


Static Gobos
o 15 high-precision gobos, plus 4 open

 Color Wheel
o Color Wheel : 12 colors plus open

Electrical and Connectors
o Power supply with electronic auto-ranging
o Input voltage range: 100-220V~ 50/60Hz
o Power consumption: 347 W
o Power In：Power Connector in
o Data In: 3pin XLR, True One connector

Fixture Specification
Fixture dimensions:
o Height: 810 mm (30.4")
o Width: 326 mm (12.83")
o Depth: 473 mm (18.62")
o Weight: 31.58 kg (69.62lbs)

Flight Case Dimensions:
o Height: 935 mm (36.8")
o Width: 505 mm (19.9")
o Depth: 605 mm (23.8")
o (Light in flightcase )Weight: 71kg (32.2.lbs) (Single Loader Case)

Work environment
o Maximum ambient temperature: 40°C
o Maximum surface temperature: 65°C
o Minimum operating temperature: -25°C
o Protection Rating: IP65

Factory configuration
o Digital User Manual
o Power Cable
o 2x Fast-lock clamps for 50mm truss
