LY -2000CC
LY -2000CC
| Parameter
Model
LY -2000CC
Light source
Main light 144pcs 3W white light beads, auxiliary light 672pcs RGB 3-in-1 light beads
Beam Angle:80° for white light band, 120° for auxiliary light
LED life expectancy: 50,000hrs
Movement
Resolution: 8-16 Bit
Control and Program
Display:LED display
Protocol: DMX-512, Manual
DMX Channel: 6CH/17CH/20CH/21CH/298CH/310CH
Cooling
Dual temperature control protection system
Effects
Support pixel control, the main light 10-way, auxiliary light 96-way, the combination of editing tens of thousands of special effects
Dimmer: 0-100% electronic
Electrical and Connectors
Input voltage range: 100-240V~ 50/60Hz
Power consumption: 650W
Data IN/Out:3-pin XLR & 5-pin XLR
Power In/Out:Indoor power con
Fixture Specification
Fixture dimensions:
Height:550mm (21.65")
Width: 240mm (9.45")
Depth: 350mm (13.78")
Weight: 6.8kg (14.99lbs)
Work environment
Maximum ambient temperature: 45°C
Maximum surface temperature: 60°C
Minimum operating temperature: 0°C
Protection Rating: IP20
Factory configuration
Digital User Manual
Power Cable, Signal Line, Omega-Bracket, Safety Rope
