This laser light features top-quality Nichia sources from Japan, delivering powerful outputs: 10,000mW at 638nm (red), 14,000mW at 525nm (green), and 16,000mW at 450nm (blue). It operates on a global voltage range of 110-240V at 50/60Hz. Its optical system includes a unique double-layer structure with a fully sealed optical path, ensuring stability and protection from dust and moisture. Electrical specifications include a 100V-240V input range, 760W rated power, and connectors for ILDA, RJ45, DMX, and power.The control system supports ILDA, sound control, auto, DMX512, and master-slave modes with 19/32 channels. It offers 100k analog/TTL modulation and 360° rotation. Laser shows can display text, patterns, animations, beams, logos, and custom designs, controlled via American Pangolin (QS) software. Designed for outdoor use, it has an IP65 rating and operates between -20°C and 45°C with fan cooling.
Category：

PRODUCTS

Laser Light

Inquiry
Contact Us
Library Download

| Parameter

Light Source

Light source brand: Nichia (Japan)
Light source power: Red: 10,000mW@638nm*1
                      Green: 14,000mW@525nm*1
                      Blue: 16,000mW@450nm*1
Power supply voltage: 110-240v; 50/60 Hz



Optical System

Optical path sealing: unique double-layer structure, the optical path layer is completely sealed





Electrical and Interface

Input voltage range:100V-240V 50Hz/60Hz

Rated Power:760W

Connectors: ILDA, RJ45, DMX, Power



Control System

Control Mode:ILDA standard/sound control/auto/DMX512/master-slave/

Channel:19/32 Channels

Modulation mode: 100k Analog / TTL
Rotate Angle: 360°

Play angle: Max60°
Laser show: text/pattern/animation/beam/LOGO/custom

Software control:American Pangolin (QS)



Working Environment

Max ambient temperature:45°C

Minimum operating temperature:-20°C

Environment: Outdoor IP65

Cooling method: Fan cooling



Light Size/Weight:

Light Size：510×438×226mm (Handle Height Included)

Net Weight: 36kg

Net Weight: 52kg

Flight case size:670×600×400mm
