150W LED BEAM MOVING HEAD LIGHT
HL-150LB
Library Download
| Parameter
Light Source
Module:150W led module
Lumen:7600lm
LED Lifespan:20000hours
Optical System
Optical Lens:High precision glued optical lens
Beam Angle:2.8°
Electrical and Interface
Input voltage range:100V-240V 50Hz/60Hz
Rated Power:200W
Power:Power In/Out
Signal:3 Pin Signal In/Out
Housing Material
Housing: High temperature resistant alloy plastic +plastic handle Control And Program
4pcs Press Button
Control Panel:LED LCD screen
Control Mode:DMX512,RDM,Auto and user Program
DMX Channel:1 kind
Channel:15Channels
Prism
Rotating 8-facet prism
X Axis/Y Axis
XY Motors:Super Silence, Ultra fast 3-phase step motors XY infinite rotation
X axis /Y axis position automatic correction if out of step
Working Temperature
Max ambient temperature:45°C
Minimum operating temperature:0°C
Max surface temperature:80°C
Light Size/Weight:
Light Size：300*225*393cm 8.5kgs
Light Size：11.82*8.86*15.47in, 18.74lbs
| Size
| Lux
| Effects
